Lady-Herkomer Bridge (Landsberg am Lech)

The Lady-Herkomer-Steg not only connects two sides of the river, but also marks a decisive step towards the turnaround in mobility and the city vision of Landsberg 2035. The building, which was subsidized by ehret+klein with €1.3 million, will in future not only serve to provide fast and car-free crossing of the Lech, but also creates a direct connection between the old town of Landsberg and urban life on the Papierbach. A win for both sides!Source: ehret-klein.de/aktuelles/eroeffnung-des-lady-herkomer-steges-in-landsberg-am-lechStructural steel for bridge body: 321 t
Gravel for the gravel bank in the Lech approx.: 8,000 m3
Concrete: 518 m3
Reinforcing steel: 137 t
Bored piles total length: 304 m
Excavation: 1,890 m2
Superstructure width: 5.50 m to 7.40 m
Total span: 130 mSource: bertl-magazin.de/der-lady-herkomer-steg

NUMBERS, DATA, FACTS
Structural steel for bridge body: 321 t
Gravel for the gravel bank in the Lech approx.: 8,000 m3
Concrete: 518 m3
Reinforcing steel: 137 t
bertl-magazin.de/der-lady-herkomer-steg

A pedestrian bridge over the Lech illuminated at night.
Very nice for a walk!
